Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing

Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing

Automatic Computing CCD Rice Color Sorter

5400Pixel CCD Rice Color Sorter

Automatic Computing Rice Sorting Machine

Place of Origin:

China

Brand Name:

WENYAO

Certification:

CE & ISO9001

Model Number:

WYCS5-320

Contact Us

Request A Quote
Product Details
Function:
Color Sorting
Sorting Accuracy(%):
≥99.99
Condition:
New
Color:
Blue,according To Customer's Need
Warranty:
2 Years
After-sales Service Provided:
Engineers Available To Service Machinery Overseas,Field Installation,commissioning And Training,Overseas Service Center Available,Field Maintenance And Repair Service
Application:
Dehydrated Vegetable Colour Sorter
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
USD 16800-17800 1PCS
Packaging Details
Plywood case package Packing size(L*W*H):1.92*1.72*2.05M
Delivery Time
7-10 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
200PCS Per Month
Product Description
Product Description
WENYAO Automatic Computing CCD Rice Color Sorter For Grain Processing


WENYAO Color Sorter provides a high-precision rice sorting solution for all types of rice. Whether it’s freshly harvested rice or long-term storage rice in the warehouse, it is impossible to avoid problems of lesions, impurities, breakage, even moldy rice.

These problems are also threatening our food safety at all times. WENYAO Color Sorter is designed to separate fine rice from the original rice materials, which will greatly improve your production efficiency.

WENYAO Color Sorter is not only used for regular rice like long-shaped rice, round-shaped rice, and sticky rice, but it is also used for other types of rice such as black rice, yellow rice, rose rice, and even high glutinous rice. The sorting accuracy at one time is close to 99.9% and a single chute sorting capacity is less than 1.3 ton per hour.

Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 0

MODEL(Technical Parameters) WYCS5-320
Channels 320
Output(kg/h) Depend on raw material impurity 2000-6000
Sorting Accuracy(%) ≥99.9
Carryover Rate(bad:good) ≥13:1
Power Supply(KW) 2.9
Work Air Pressure(Mpa) 0.2-0.3
Air Consumption(L/min) 1300-2800
Voltage 180-240V/50Hz
Weight(kg) 900
Diamension/Size (L*W*H)mm 2244*1540*1852
Package Wooden Case
* The data of the machine overall dimensions are for reference only, specific dimension will be subject to the installation drawing

Parts Detailed Photo


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 1


CCD Camera
*5340 linear CCD camera with high precision allows high definition identification and high speed sorting.
*Most advanced ccd technology can sort materials accurately.
*Toshiba CCD sensor
*American process chip



Self-developed Solenoid Valve
*WenYao mechanical ejector with scientific design can make machine work stably for long time.
*A new type of high frequency valve allows for low consumption of electricity , long life reaction speed, high durability, easy
maintenance, and improved color accuracy.

Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 2


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 3


Adjustable LED Light Source
*Configuration of the special light source allows for ten million kinds of color sorting with a fully adjustable colourspectrum.
*Materials can be sorted according to different configurations which is suitable for various sizes of sorting, no need to change
the light source.



Intelligent computing integrated circuit
With unparalleled high performance and low abilityconsumption, the industry's highest Bandwidth andintegration, processing ability increased 5 times.

Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 4


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 5


Humanized interface
*Humanized touch panel, easy to learn, more convenient to operate.Concise touch panel helps customer operate easily and promptly.
*High quality FPGA processing technology, defects of 0.04mm2 can be detected.

Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 6
Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 7


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 8
Packing & Delivery


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 9
*Process visualization
From manufacturing to shipment, all processes can be supervised in real time according to your requirements.
And we welcome you to visit our factory in person.



Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 10

Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 11

In customer site


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 12


In Our Europe Customer Working Plant.


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 13

In Our Southeast Asia Customer Working Plant.


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 14





In Our South Asia Customer Working Plant.

Our Factory&Customer


Wenyao Automatic Computing CCD Rice Color Sorter For Grain Processing 15


ANHUI WENYAO Optoelectronic Technology Co., Ltd founded in 2007, which combined with design, manufacture and selling. We manufacture high-tech optical color sorter machine of sorting wheat, rice, tea, melon seeds, grains, coarse cereals, nuts, dried vegetables, dried seafood, plastics, ores, ect. Supply the service to customers from Asia, the Middle East European, South Africa and African markets.


Through countless cooperation and OEM service with international partners, ANHUI WENYAO has streamlined the proper procedures and processes and opened up professional techniques that are ahead of the color sorting field and delivered the highest-quality products to every corner of the world.


Through countless hardwork, we serve customers from all over the world. We have high reputation in domestic, Africa, Middle-East, South-East Asia market. Expect you to join our big family. We will never let you down.


FAQ


1. How to use the machine?
We will supply the Installation instructions or video and our engineers will train your operators.



2. How long about the guarantee period?

One year. And we supply lifelong software upgrade services for our customers.

3. Can you supply the air compressor, air tank and air filters?
Yes, we can provide above equipments, our standard offer includes color sorter machine with air compressor, air tank and filters.


4. Is oversea service available?

Yes, our engineers could go abroad when required.

5.How to calculate Installation personnel cost?
On condition that customer requires to install, our company would like to send 1 Engineer to guide for installation, then customer should to pay the cost, including transaction of Engineer's visa, transportation(air) for go abroad. and accommodation , local transportation and security when the Engineer arrived.
