Name: High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light
Brand: Anhui Wenyao Intelligent Photoelectronic Technology Co., Ltd
SKU: WYB1
Price: 22,500.00 USD
Availability: InStock

Home > products > Belt Color Sorter >

High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light

High Throughput Belt Color Sorter

LED Variable Light Glass Sorting Machine

High Throughput Glass Sorting Machine

Place of Origin:

China

Brand Name:

WENYAO

Certification:

CE & ISO9001

Model Number:

WYB1

Request A Quote

High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light

Product Details

Sorting Accuracy(%):

≥99.9

Color:

Blue Frame Or According To Customer Requests

Chutes:

Channels:

128

Remote:

Wifi Remote Control

CCD:

Toshiba

Camera:

RGB Camera

Certificate:

CE & ISO9001

Lamp Source:

LED Variable Light

Application:

Glass Sorting

Hopper:

Stainless 304 Food Grade

Warranty:

2 Years

Type:

New

Throughput:

0.5-1t/h

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

Negotiable

Packaging Details

Plywood case package

Delivery Time

7-10 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

200PCS Per Month

Automatic Cashew Color Sorting Process WENYAO Color Sorter Cashew Nut Color Sorter Machine

Get Best Price

Video

Belt Chili Pepper Color sorter Chili Color Sorter Machine, 220V Precision Color Sorter Sorting Machine

Get Best Price

Video

Intelligent Peeled Garlic CCD Belt Color Sorter Customizable

Get Best Price

Video

Almond Nuts Color Sorter Machine Macadamia Nuts Walnuts Belt Color Sorter Vegetable Color Sorter

Get Best Price

+86 13855135585

service@wycolorsorter.com

+86-551-67699185

Contact Now

Product Description

High Throughput Belt Type Glass Color Sorter Glass Sorting Machine

Glass color sorter working principle:

High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light 0

When wenyao color sorter is working, feed hopper in the materials under the action of vibrator is uniform distribution in each chute. The CCD signal while the materials are dropping is in testing. If it is found that there are unqualified materials or impurities in the materials, the ejector will blow the defective goods in the hopper.

Technical Parameters:

MODEL	WYB1
Chutes/Channels	1/64
Throughput(t/h)	1-2t/h
Sorting Aaccuracy	≥99.9%
Power	1.5kw
Power Voltage	180-240V/50Hz
Air Source Pressure	0.6-0.8Mpa
Air Consumption	<0.6M3/Min
Weight	450kg
Diamension(LWH)	245010101539mm

Throughtput:Different impurity with different throughput.

Features:

1. Camera

leading in the industry

International well-known brand customized lens
Import high-end 5400PIXEL CCD sensor
High-speed of scanning
The highest resolution comes to 0.02 mm²

2. High-frequency Solenoid Valve

High-quality high-frequency solenoid valve, with consistency of near zero error.

Service life more than 1 billion times.
Ultra high precision, leading in China

3. Intelligent Image Processing Algorithm

The combination of colors and shapes of intelligent algorithm
Precise professional sorting solutions

4. Customized Lighting System

Advanced LED optical design system.
Various light sources are available to suit different materials.
Designated procurement of imported LED lamps,Higher stability, longer service life.
LED lighting system with thermal dissipation.

5. Data Transmission System

high-speed and stable
High anti-jamming, high transmission speed, high stability

6. Human-Computer Interface

simple and easy to operate

More intelligent, easy operation, one button for professional sorting, remote debugging, remote diagnosis, remote software upgrading.

Examples of nuts color sorting:

High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light 1

High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light 2

High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light 3

High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light 4

High Throughput Belt Color Sorter , Glass Sorting Machine LED variable light 5
