10 Chutes Rice Sorting / Cleanning Machine Rice Color Sorter With High Performance In Japan Thailand
Wenyao rice color sorter Features:
1. CCD core intelligent sensor.
2. Original intelligent image processing algorithm.
3. Brainlike thinking intelligent embeddedchip chip.
4. Fast and accurate color sorting solution.
5. High efficiency and high quality nozzil system+accurate and excellent remove rate.
6. Most advanced LED optical technique; imported LED light; durable and stability.
Wenyao color sorter working principle:
According to the difference in the color of the material, the equipment that automatically sorts the different-colored particles in the granular material.
Steps:
1. Raw Material are put into the machine from its feeding hopper on the top.
2. Vibrated by vibration device and sliding along material chute into the zone of observation in sorting chamber through sensor and background plate .
3. Under the effect of light source, CCD sensor receives compound light from materials being sorted.
4. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve to work ,ejecting the discolor grain to defect chamber and good materials continue to fall into the finished goods chamber.
Wenyao color sorter technical parameters:
| MODEL | WYCS10-640 |
| Chutes/Channels | 10/640 |
| Throughput(t/h) | 10-15t/h |
| Sorting Aaccuracy | ≥99.99% |
| Power | 6.5kw |
| Power Voltage | 180-240V/50Hz |
| Air Source Pressure | 0.6-0.8Mpa |
| Air Consumption | <5M3/Min |
| Weight | 1800kg |
| Diamension(L*W*H) | 3750*1540*1852mm |
Wenyao color sorter application:
Rice:rice,millet,parboil rice,black rice,red rice,brown rice,broken rice,glutinous rice,paddygolden rice,and so on.
Grains:corn,sesame,oat,barley,rye,quinoa,wheat,buckwheat and so on.
Nuts:Peanut, walnut, almond, pine nut, hazelnut, white fruit, cashew, hazelnut,chestnut, pistachio, macadamia nut ,pecan,candle nut,areca nut
Seeds:sunflower seed, pumpkin seed,watermelon seed,lotus, sesame,hump seed,flax seed,pepper,coriander seed,veget seed and so on
Beans:red beans,kidney beans,coffee bean,black beans,mung beans,broad beans,chickpea,lentil,white bean,pea and so on
Industries:plastic,Waste Plastics, Plastic pellet, Plastic pieces, Plastic granule, Plastic bottle cap flake, PET bottle scrap, ABS plastic flake, PP plastic scrap, Recycled plastic,electronic component,industrial salt,quartz sand,metal,glass
tea leaf:black tea,green tea,herbal tea,flower petal tea,ceylon tea,oolong tea.
Others:raisins,wolfberry,pepper,chili,spice,fish,shrimp
Examples of color sorting:
Note:The machine support more than 2500 materials ,welcome to inquire us for more details.
