CCD Seed Kernel Color Sorter Machine Sorting For Watermelon Seed Color Separator With Best Price

CCD Seed Kernel Color Sorter Machine Sorting For Watermelon Seed Color Separator With Best Price

Working principle :
Raw Material are put into the machine from its feeding hopper on the top, vibrated by vibration device and sliding along material chute into the zone of observation in sorting chamber through sensor and background plate.Under the effect of light source, CCD sensor receives compound light from materials being sorted.According to the light intensity and color changes,make the system produce output signal and drive solenoid valve to work ,ejecting the discolor grain to defect chamber and good materials continue to fall into the finished goods chamber.

Features:

*Latest UHD imaging and analysis technology,high-speed processing,accurate identification

*High level AI self-learning function,one-key automation,user friendly interface,easy operation

*High and specification ensures high stability,with high sorting accuracy,small carry over and low energy

*Small and portable,saving space and delivery cost,small machine but super function

*Imported ejectors,much smaller air consumption,and much better carry over,esp.good for small materials like quinoa,China,sesame....

*Option:Remote control by smart terminals like cellphone ,can realize the off-site controls of the accuracy,production capacity and halt of the machines

*Simple Effective-installation&Start-up&Commissioning services;remote teaching and guidance via live video online through internet to worldwide

How can a color sorter benefit your business?

Multi-Functional

This product can be used in agricultural, grain, oil, chemical, pharmaceutical and other industries, especially suitable for rice, tea, sesame, beans, seeds, raisins, plastic, ore, peanut, pepper, and other color sorting field.

High Efficiency

Compared with manual sorting, a color sorter machine is labor-saving, time-saving, high efficiency with much lower processing cost, it can dramatically improve material accuracy to bring economic and social benefits for customers all over the world.

Technical parameters:

Wenyao color sorter core parts:

1.Most advanced RGB cameras with 5400 pixels linear industry CCD sensor .
2.America FPGA processing chip.
3.Japan Toshiba CCD sensor.
4.Metal ejectors/valves with more than one billion lifetime
5.Lens:Japan Nikon Lens .
6.Filter: Japan CKD filter
7.Power source:Taiwan Meanwell
8.All LED light source,more longer lifetime and save power
9.Flexem Humanized touch screen
10. WIFI remote control system ,help end user to debug and monitor machine situation in chinese factory during covid-19 period,Supply non-contactness after service

Wenyao multifunction color sorter application:

Food materials:
Such as: Rice, Wheat, Corn,Oats , Buckwheat,Barley,Cassava,Peanut, Sunflower seeds, Walnut, Almond, Quinoa, Salt, Medlar, Pistachio, Kidney bean, Chili, Soybean,Red bean, black bean,chickpea,lentil,others.

Plastic materials:
Such as: Waste Plastics, Plastic pellet, Plastic pieces, Plastic granule, Plastic bottle cap flake, PET bottle scrap, ABS plastic flake, PP plastic scrap, Recycled plastic, others.

Mineral materials:
Such as: Quartz stone, Quartz sand, Potassium feldspar, Barite, Calcite, Limestone, Pearl, Marble and others.

Tea leaf materials:
Such as:Black Tea,Green Tea,Herb Tea,Corn Flower

Vegetable and fruits:
Such as: Dried Garlic ,Onion, Olive,Coffee Cherry,Jujube ,Dried fish and shrimp

Examples of color sorting:

Note:The machine support more than 2500 materials ,welcome to inquire us for more details.

Our service:

Pre-sales
We will provide detailed solutions for your special requirement and help you know more about our color sorter.
After-Sale Service
1.We will test your products at your plant, training your staff, set every file for customer to serve all round service, so as to ensure your machine working under the best situations.
2.From the date of use machine, we can provide one year free maintenance ( not the reason of vandalism and something unexpected, excluding delicate fittings) and lifetime maintenance.
3.Engineers available to service machinery overseas, we also can train technical staff for customers.We provide lifelong software upgrade services for our customers for free.

Parking and delivery:

Packaging Details:
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.
Delivery Details:
Within 15 - 20 days after received the 30% deposit.

Our customer's case:

FAQ:

1. How to install and use the machine?
We will supply the Installation instructions or videos and our engineers will train the operators.

2. How long about the guarantee period?

2 years. We supply lifelong software upgrade services for our customers.


3. Can you supply air compressor, air tank and air filters?
Yes, We can provide above equipments, Our standard offer includes color sorter machine with air compressor, air tank and filters.

4. How about after sales service?

Yes, By videos or by remote control or local service or engineers could go abroad when required.


5.Will you accept L/C as payment?
L/C ,T/T is OK.

6.Will you test machine before delivery ?

Yes , we will test carefully before delivery ,and save parameters in the machine
