WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology

WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology

FPGA Chip Beans Color Sorter

CKD Filter Beans Color Sorter

Japan Nikon Lens Beans Color Sorter

Place of Origin:

Hefei China

Brand Name:

WENYAO

Certification:

ISO9001&CE

Model Number:

WYCS7-448

Contact Us

Request A Quote
Product Details
MOQ:
1.0 Pcs
Sorting Accuracy(%):
99.95%
Condition:
Latest And Most Advanced WENYAO Brand
Power Supply:
Taiwan Meanwell
Touch Screen:
12-inch Flexem Humanized Touch Screen
Chip:
America FPGA Process Chip
Air Filter:
CKD Filter And SMC Filter
Lens:
Japan Nikon Lens
Chute:
7(448)
CCD Sensor:
Japan Toshiba CCD Sensor
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
Negotiable Price
Packaging Details
Plywood case package
Delivery Time
12-25work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
235Pieces Per Month
Product Description

Colour Sorter Coffee Beans Color Sorter Machine Color Sorting Machine

1. WENYAO  Colour Sorter Machine Working Pricinple

Raw materials are put into the machine from its material hopper on the top, vibrated by vibratiory feeder and sliding along material chute into the zone of observation in sorting chamber through sensors and background plate. Under the effect of lamps source, CCD sensor receives compound light from materials being sorted. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve(ejector) to work, ejecting the discolor grain to reject chamber and good materials continue to fall into the finished accept chamber







WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology 0



2. Technical Parameters:



MODEL WYCS7-448
Chutes/Channels 7 / 448
Throughput(T/h) 5T/h-7T/h
Sorting Aaccuracy ≥99.99%
Power 3.9kw
Power Voltage 180-240V/50-60Hz
Air Source Pressure 0.6-0.8Mpa
Air Consumption <2.8M3/Min
Weight 1350kg
Diamension(L*W*H) 2905*1540*1852mm





3. Machine Features:



Features:
1. Most advanced RGB cameras with 5400 pixels linear industry CCD sensor .
2. America FPGA processing chip.
3. Japan Toshiba CCD sensor.
4. Metal ejectors/valves with more than one billion lifetime
5. Lens:Japan Nikon Lens .
6. Filter: Japan CKD filter
7. Power source:Taiwan Meanwell
8. All LED light source,more longer lifetime and save power
9. Flexem Humanized touch screen
10. WIFI remote control system,help end user to debug and monitor machine situation in chinese factory during covid-19 period,Supply non-contactness after service



4. Examples of Color Sorting Examples



WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology 1



How to get the correct size and suitable price of wenyao color sorter machine?


Step 1. Which kinds of the material do you want to sort ?


Step 2. How much input capacity for the raw materials per hour?


Step 3. In order to know the impurity rate of the raw materials which are needed to be sorted, please send us 3 pictures as following:
1. Raw material picture(feeding in the machine materials)
2. Accepted material picture(you want to save the good materials)
3. Rejected material picture(you want to sort out the bad materials)



5. Our Service:


A: For software:We have installed WIFI remote control system on machine,Once machine arrived in your local we will connect with machine touch screen provide technical assistance from Chinese factory.


B:For hardware:We will supply you the spare parts ship together with machine,In case you face hardware problems,we will guide you how to repair by live videos.


6.Packing and Delivery:

Packaging Details:
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.



Delivery Detail:
Within 15 - 20 days after received deposit.



WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology 2

WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology 3WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology 4WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology 5WENYAO Coffee Beans Color Sorter with Advanced Sorting Technology 6

7.FAQ

1. How to use the machine?
We will supply the Installation instructions or video and our engineers will train your operators.

2. How long about the guarantee period?two year. And we supply lifelong software upgrade services for our customers.

3. Can you supply the air compressor, air tank and air filters?
Yes, we can provide above equipments, our standard offer includes color sorter machine with air compressor, air tank and filters.

4. Is oversea service available?
Yes, our engineers could go abroad when required.

5. How to calculate Installation personnel cost?
On condition that customer requires to install, our company would like to send 1 Engineer to guide for installation, then customer should to pay the cost, including transaction of Engineer's visa, transportation(air) for go abroad. and accommodation , local transportation and security when the Engineer arrived.





Maintenance :

Dedusting
Deash brush

Clean dusts on the rubber strip of the deash brush once a week by ash gun; check the deash brush once a month, if any loose, tighten it. Correct the rubber strip if it cannot operate steadily.

Dedusting for sorting cabinet
If any dust found on the glass inside the sorting box, rub and remove it with clean soft cloth soaked with alcohol, and check if dust wiper works normally. Start machine only after glass surface completely dried and cleaned.

Sewage discharging for filter and replacement of filter element
Sewage discharging for filter
Ambient temperature around the machine should be maintained at 0-40.
In places with night temperature may lower than 0, residual fluid inside the air compressor and air filter shall be removed after shutdown of machine. With the water discharging function, the air compressor and oil-mist separator will automatically discharge water when it reaches to certain height, while it would be difficult to discharge water as the water discharging port will be frozen when the temperature is below 0. Thus, it is required to discharge water manually.
If operate the machine with the compressed air temperature lower than 0, air supplied for the air filter and oil mist separator shall be dried by the air drier as the moist air would frozen the internal filter element, which hampers the air flow and cause damage to the filter element.
