4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA

4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA

bean color sorter

bean sorting machine

4 Chutes Green Bean Color Sorter

Place of Origin:

AnHui China

Brand Name:

WENYAO

Certification:

CE & ISO9001

Model Number:

WYCS4-256

Contact Us

Request A Quote
Product Details
After-sales Service:
Engineers Overseas
Name:
Beans Color Sorter Machine
Accuracy(%):
≥99.30
Condition:
2022 Hot Sale
Color:
Customized Color
Warranty:
2 Years
Camera:
Toshiba Brand
Chip:
FPGA Processing Technology
Filter:
CKD & SMC
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
Negotiate price
Packaging Details
Plywood case package Packing size(L*W*H):1.70x1.0x1.55M
Delivery Time
7-15 Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
200PCS Per Month
Product Description

4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA



4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 0



4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 1


Features:

►Automatic computing and intelligent identification with high speed camera.
►5400Pixel CCD image acquisition system with high speed chip.

►Intelligent dust cleaning system,It means you can set cleaning time and period according to your need.
►Self design high frequency ejectors,It means high speed and accurate sorting performance.
►Low temperature LED light source system,Cooling system to make the LED lamp more long life.

►WIFI remote control system,It means color sorter connecting to the internet,You can use mobile phone or computer to operate color sorter.

►Easy to use touch screen in English,Spanish,German,Russian and so on more than 20 languages.





Examples of color sorting:

4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 2



4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 34 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 44 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 5



Technical Parameters:

Model WYCS1-64 WYCS2-128 WYCS3-192 WYCS4-256
Chute/Channel 1/64 2/128 3/192 4/256
Throughput(t/h) 1 Ton /H 0.6-2.5 Ton /H 1-4 Ton /H 1.4-5 Ton /H
Sorting Aaccuracy ≥99.99% ≥99.99% ≥99.99% ≥99.99%
Power 0.75kw 1.1kw 1.6kw 2.3kw
Power Voltage 180-240V/50Hz 180-240V/50Hz 180-240V/50Hz 180-240V/50Hz
Air Source Pressure 0.6-0.8Mpa 0.6-0.8Mpa 0.6-0.8Mpa 0.6-0.8Mpa
Air Consumption <0.6M3/Min <0.6M3/Min <0.6M3/Min <0.6M3/Min
Weight 280kg 450kg 600kg 750kg
Diamension(L*W*H) L780*W1527*H1543mm L1250*W1535*H1832mm L1620*W1535*H1832mm L1855*W1540*H1852mm




4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 6

Key Components:

1. Automatic computing and intelligent identification with high speed camera.
2. 5400Pixel CCD image acquisition system with high speed chip.

3. Intelligent dust cleaning system,It means you can set cleaning time and period according to your need.
4. Self design high frequency ejectors,It means high speed and accurate sorting performance.
5. Low temperature LED light source system,Cooling system to make the LED lamp more long life.

6. WIFI remote control system,It means color sorter connecting to the internet,You can use mobile phone or computer to operate color sorter.

7. Easy to operate touch screen with english,spanish,german,russian and so on more than 20 languages.



Customers

4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 7

4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 8

4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 94 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 104 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 11

4 Chutes High Capacity Automatic Yellow Bean Green Bean Color Sorter Popular in the USA 12
