CCD Optical RGB CCD Coffee Bean Kidney Bean Mung Bean Sorting Machine 1 Chutes Made in China
Beans Color Sorter Provide you with a full set of color sorting quality upgrade solutions. Soybeans can be sorted: different colors, moldy black, dry beans, stones, broken skins, etc., intelligent sorting, quality upgrades, and let your soybeans sell at higher prices.
Working Principle:
Raw materials are put into the machine from its material hopper on the top, vibrated by vibratiory feeder and sliding along material chute into the zone of observation in sorting chamber through sensors and background plate. Under the effect of lamps source, CCD sensor receives compound light from materials being sorted. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve(ejector) to work, ejecting the discolor grain to reject chamber and good materials continue to fall into the finished accept chamber.
Application Scope:
White beans, lentils, broad beans, black beans, red beans, soybeans, frame beans, coffee beans, cocoa beans, mung beans, edamame, peas
Main features:
►Automatic computing and intelligent identification with high speed camera.
►5400Pixel CCD image acquisition system with high speed chip.
►Intelligent dust cleaning system,It means you can set cleaning time and period according to your need.
►Self design high frequency ejectors,It means high speed and accurate sorting performance.
►Low temperature LED light source system,Cooling system to make the LED lamp more long life.
►WIFI remote control system,It means color sorter connecting to the internet,You can use mobile phone or computer to operate color sorter.
►Easy to operate touch screen with english,spanish,german,russian and so on more than 20 languages.
Technical Parameters:
| Details as following | |
| MODEL | WYCS1-64 |
| Chutes(channels) | 1(64) |
| Sorting accuracy(%) | ≥99.9 |
| Carryover rate (bad:good) | ≥12:1 |
| Output(kg/h) | 500-800 |
| Voltage | 180-240V/50Hz/60hz |
| Power supply(kw) | 0.9 |
| Work Air Pressure(Mpa) | 0.2-0.3 |
| Air consumption(L/min) | 200-600 |
| Air supply(Mpa) | 0.6--0.8 |
| Dimension(L*W*H) mm | 900*1520*1350 |
| Weight(kgs) | 280 |
| Package | plywood case |
| Package Size mm | 1040*1660*1540 |
Examples of color sorting:
How to get the correct size and price for wenyao color sorting machine?
Step 1.What kinds of the material are you planning to sort processing?
Food materials:
Such as: Rice, Wheat, Corn, Soybean, Peanut, Sunflower seeds, Waltnut, Almond, Quinoa, Salt, Medlar, Pistachio, Kidney bean, Chili, Red bean, others.
Plastic materials:
Such as: Waste Plastics, Plastic pellet, Plastic pieces, Plastic granule, Plastic bottle cap flake, PET bottle scrap, ABS plastic flake, PP plastic scrap, Recycled plastic, others.
Mineral materials:
Such as: Quartz stone, Quartz sand, Potassium feldspar, Barite, Calcite, Limestone, Pearl, Marble and others.
Step 2.How much capacity(output) to sort processing for the raw materials per hour?
Such as: 200KGS, 500KGS, 1000KGS, 2000KGS and son on.
Step 3.In order to know the impurity rate of the raw materials that are needed to be sorted, please send us 3 pictures as following:
1. Raw material picture 2. Accepted material picture 3. Rejected material picture
Customer Sites:
Packaging & Shipping
Machines to be carefully packaged to endure transportation under harsh conditions. Handling instructions are designed to protect the machine in the critical moments during transportation, unloading and installation.
Delivery Time: 20- 30 Days after order confirmed.
Payment Terms: TT, Letter of Credit.
Commissioning and Installation:
1. On Site Installation and Training Service by our professional engineer ;
2. Study and Learn the Machine Operation in Our Factory.
3. Responsive in 24 hours: Telephone, Email, Video or On Site Solutions by our Technical Experts.
After Sales Services:
• With presence in a variety of countries, we are strongly committed to being close to the customer.
• Through cooperation with loyal and carefully evaluated and trained local employees and partners, we are managed to provide fast, competent and rooted services in the context of customers.
• Application center in Hefei production base offer demo machines for tests and comparison.
• A strong central technical team in Hefei is supporting local channels with training, advice and technical support.
• Under normal working circumstances, Our machines enjoy 2 years of full warranty and a lifelong warranty on the machine structure upon the date of purchase.
• Service line is available for emergency support.
