Smart 8 Chutes Wheat Paddy Grain Color Sorter CCD Optical CE ISO9001 CE

Smart 8 Chutes Wheat Paddy Grain Color Sorter CCD Optical CE ISO9001 CE

Grain Sorter 8 Chutes

Grain Color Sorter ISO9001

Grain Color Sorter Easy Operate

Place of Origin:

China

Brand Name:

WENYAO

Certification:

CE & ISO9001

Model Number:

WYCS8-512

Contact Us

Request A Quote
Product Details
Machine Name:
Grain Color Sorting Machine
Sorting Accuracy(%):
≥99.99
Ejector:
Metal
Warranty:
2 Years
Certificate:
CE&ISO9001
Key Selling Points:
Easy To Operate
Marketing Type:
New Product 2021
Application:
Rice Processing,sorting,wheat,grain Cleaning And Separator
After-sales Service Provided:
24/7 Online After-sale Support
Color:
Blue,according To Customer's Need
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
Negotiable
Packaging Details
Plywood case package Packing size(L*W*H):3.95*1.72*2.05M
Delivery Time
7-10 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
200PCS Per Month
Product Description

Smart 8 Chutes Wheat Paddy Grain Color Sorter CCD Cereal Optical Sorting Machine Separator CE ISO9001 CE



Wenyao color sorter working principle:

Input product is loaded into the in-feed hopper , it moves along the vibrating plate , until it flows on to a sloping chute, where it is individually checked at 360° and sorted by RGB Full color cameras .

Depending on the signals received by the optical device, the sorter's software controls the pneumatic device, which physically separates the unwanted products out of the conforming ones, which naturally reach their discharging hopper.

Smart 8 Chutes Wheat Paddy Grain Color Sorter CCD Optical CE ISO9001 CE 0

Wenyao color sorter Features:

1.It adopts high quality special industrial lenses;

2.Self checking system,5400 CCD camera, and photo processing technology.

3.High speed FPGA technology signal processor with fast detection and high identification rate.

4.Overall unit adopts intelligent closed-loop control.

5.High speed air value is used to ensure quick response, low power consumption and long service life.

6.It uses intelligent temperature and air pressure control technology in order to ensure the best operative mode for the whole machine.

7.Failure alarm automation and modular construction makes easy repair.

8.Combining LED lighting systems with fixed backgrounds and low voltage vibrator, auto-adjusts varying light levels, minimizing vibrations and producing consistent throughput across the chute.

Wenyao color sorter technical parameters:

MODEL WYCS8-512
Chutes/Channels 8/512
Throughput(t/h) 7-16t/h
Sorting Aaccuracy ≥99.99%
Power 5kw
Power Voltage 220V/50Hz
Air Source Pressure 0.6-0.8Mpa
Air Consumption <5M3/Min
Weight 2000-4000L/min
Diamension(L*W*H) 3025*1540*1852mm



Application:

Rice:rice,millet,parboil rice,black rice,red rice,brown rice,broken rice,glutinous rice,paddygolden rice,and so on.



Grains:corn,sesame,oat,barley,rye,quinoa,wheat,buckwheat and so on.



Nuts:Peanut, walnut, almond, pine nut, hazelnut, white fruit, cashew, hazelnut,chestnut, pistachio, macadamia nut ,pecan,candle nut,areca nut



Seeds:sunflower seed, pumpkin seed,watermelon seed,lotus, sesame,hump seed,flax seed,pepper,coriander seed,veget seed and so on



Beans:red beans,kidney beans,coffee bean,black beans,mung beans,broad beans,chickpea,lentil,white bean,pea and so on



Industries:plastic,Waste Plastics, Plastic pellet, Plastic pieces, Plastic granule, Plastic bottle cap flake, PET bottle scrap, ABS plastic flake, PP plastic scrap, Recycled plastic,electronic component,industrial salt,quartz sand,metal,glass

tea leaf:black tea,green tea,herbal tea,flower petal tea,ceylon tea,oolong tea.



Others:raisins,wolfberry,pepper,chili,spice,fish,shrimp and so on.



Parking and delivery:

Smart 8 Chutes Wheat Paddy Grain Color Sorter CCD Optical CE ISO9001 CE 1

Smart 8 Chutes Wheat Paddy Grain Color Sorter CCD Optical CE ISO9001 CE 2

Packaging Details:
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.

Delivery Details:
Within 15 - 20 days after received the 30% deposit.

FAQ:

1. How to install and use the machine?
We will supply the Installation instructions or videos and our engineers will train the operators.



2. How long about the guarantee period?

2 years. We supply lifelong software upgrade services for our customers.


3. Can you supply air compressor, air tank and air filters?
Yes, We can provide above equipments, Our standard offer includes color sorter machine with air compressor, air tank and filters.



4. How about after sales service?

Yes, By videos or by remote control or local service or engineers could go abroad when required.


5.Will you accept L/C as payment?
L/C ,T/T is OK.



6.Will you test machine before delivery ?

Yes , we will test carefully before delivery ,and save parameters in the machine
