Wifi Remote Control Grain Color Sorter For Versatile Applications

Wifi Remote Control Grain Color Sorter For Versatile Applications

220v Grain Sorting Machine

Wifi Remote Control Grain Color Sorter

Versatile Grain Color Sorter

Place of Origin:

Hefei,China

Brand Name:

WENYAO

Certification:

CE,ISO9001,SGS,TUV

Model Number:

WYCS8-512

Contact Us

Request A Quote
Product Details
Function:
Color Sorting Machine
Sorting Accuracy(%):
≥99.99
Machine Color:
White Or Customized
Light Source:
LED
Warranty:
2 Years
After-sales Service Provided:
Engineers Available To Service Machinery Overseas,Field Installation,commissioning And Training,Overseas Service Center Available,Field Maintenance And Repair Service
Ejector:
Japan SMC
Application:
Rice,wheat,grain,nuts,seed,plastic,mineral
Voltage:
220V/50~60HZ
Feature:
Easy To Operate ,high Sorting Accuracy
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
Negotiable
Packaging Details
Standard Plywood wooden box
Delivery Time
10-15 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
200PCS/Month
Product Description

High Performance Grain Color Sorter with Wifi Remote Control for Versatile Applications



Advantage :



1, the introduction of LED Air Cooling
Solve the LED light source due to prolonged use of high temperature, short life and other issues, ensuring constant LED light source durable.
2, the unique suction ventilation system
You can remove dust and other raw materials in the ethereal substance, to ensure that the lens identification, higher color sorting accuracy.
3, the image acquisition system
Full-color high-definition CCD camera image acquisition system, the material (RGB) red, green, and blue color information to obtain a comprehensive, small depth to identify and elaborate common color sorter can not choose other impurities.
4, the operating system
Intelligent operating platform, easy to operate, easy to master, the real man-machine dialogue, intelligent docking, sit back and relax.
5, the image processing system
International high-end full-color line scan technology, DSP + FPGA processing the international forefront of technology, combining a variety of colors and shapes model complex algorithms, to provide “color selection + shape selected” function for different materials, a variety of modes set free.




High Resolution Intelligent Metal Copper Aluminium Scrap CCD Optical Sensor Color Sorting Machine



Color sorter work principle:

Wifi Remote Control Grain Color Sorter For Versatile Applications 0


Working principle CCD color sorter CCD digital camera to material is adopted signal acquisition.Analyze the collected signals, handling, comparison, to eliminate beyond the value of the material.
Color selection process as shown:

Color sorter at work,Feed hopper in the material under the action of vibrator is uniform distribution in each chute,The CCD signal of the whereabouts of the material in testing,If it is found that there are unqualified material or impurities in the material,The startup ejector to blow the defective goods in the hopper.(Above only for the working process of the diagram,The actual material shall prevail.)







Sorting Performance





Wifi Remote Control Grain Color Sorter For Versatile Applications 1

Wifi Remote Control Grain Color Sorter For Versatile Applications 2

Wifi Remote Control Grain Color Sorter For Versatile Applications 3

Wifi Remote Control Grain Color Sorter For Versatile Applications 4

Wifi Remote Control Grain Color Sorter For Versatile Applications 5





Technical Parameter:

MODEL WYCS8-512
Chutes(channels) 8(512)
Sorting accuracy(%) ≥99.9
Carryover rate (bad:good) ≥30:1
Output(T/h) ≥2
Voltage 180-240V/50Hz
Power supply(kw) 5
Work Air Pressure(Mpa) 0.2-0.3
Air consumption(L/min) 2000-4000
Air supply(Mpa) 0.6--0.8
Dimension(L*W*H) mm 3010*1545*1860
Weight(kgs) 1500
Package Plywood case
Package Size mm 3165*1680*2042

From Customer's Site :



Wifi Remote Control Grain Color Sorter For Versatile Applications 6Wifi Remote Control Grain Color Sorter For Versatile Applications 7Wifi Remote Control Grain Color Sorter For Versatile Applications 8Wifi Remote Control Grain Color Sorter For Versatile Applications 9Wifi Remote Control Grain Color Sorter For Versatile Applications 10Wifi Remote Control Grain Color Sorter For Versatile Applications 11Wifi Remote Control Grain Color Sorter For Versatile Applications 12



Recommended Applications:

RiceWifi Remote Control Grain Color Sorter For Versatile Applications 13

Wheat

Peanuts

Seeds

Grains

Beans and Pulses

Why choosing Wenyao

1,Advanced image acquisition system
Wenyao color sorter machine use the high resolution monochromatic camera or RGB camera(5000+ pixels) with high quality industrial lens to achieve clear and accurate image acquisition.The camera could capture the micro defects of material instantly.

2,Intelligent image processing algorithm
Color sorting algorithms of gray level,color difference and HSV are perfectly combined with shape sorting algorithms of size,circular degree,texture etc,and successfully solved a series of high difficulty color sorting problems,and dramatically enhance the sorting accuracy.

3,Unique chutes processing technology
The special anodizing and hardening technology can greatly improve the channel smoothness and ware resistance to guarantee high production.

4,High quality solenoid valve(ejector)
Wenyao color sorters are equipped with high quality solenoid valve.The valve has longer lifespan,high frequency and low air consumption.The working frequency is 1000 times per second,which guarantees the accurate and perfect ejecting.For the different sizes and characteristics of material particle, Wenyao optical sorters use the solenoid valve of different sizes.

5,High efficiency and reliable light source
Advanced LED lighting technology with advantages of super high intensity,long lifetime&perfect performance.

6,Simple operation, easy to learn and use
Simple optical system design, precise automatic correction system, combined with the well-designed human-machine interface to simplify the complexity of machine commissioning and use, ensuring the simple operation and the machine is easy to learn and use.
