Place of Origin:
Hefei China
Brand Name:
WENYAO Brand
Certification:
CE & ISO9001
Model Number:
WYCS5-320
Contact Us
1.Color high-resolution CCD image acquisition system
Our color sorting uses color CCD image acquisition system, which can acquire full color information of red, green and blue material. This enables our sorter to better suit customers’ requirements.
With a max resolution of 0.15mm, it can accurately detect the small defects and spots of beans .The high precision lens helps ensure the image more clear and accurate
2.Specialized image processing algorithm
Considering the complexity of beans , we use complicated regional classification method and realize material analysis and classification within the color gamut, so the accuracy of material identification is assured.
3.Unique feeding system
Due to its adjustable module design, the feeding system can accommodate various kinds of beans for a wider application range of color sorting
Special chute design ensures the uniformity of material flow , the best image accquistion and defective material rejection effects can be achieved.
4.Optional quality ejector
For materials of small grains , the imported high frequency ejector is more effective .
For materials of larger grain ,the imported large air flow high frequency ejector is more effective .
5.High rejection rate
High rejection rate is accomplished as a result of our high resolution CCD, unique feeding system , specialized algorithm and ejector.
2. Technical Parameters:
MODEL | WYCS5-320 |
Chutes/Channels | 5 / 320 |
Throughput(kg/h) | 3000kg/h-4000kg/h |
Sorting Aaccuracy | ≥99.99% |
Power | 2.9kw |
Power Voltage | 240V/50Hz or Customized |
Air Source Pressure | 0.6-0.8Mpa |
Air Consumption | <2.8M3/Min |
Weight | 900kg-910kg |
Diamension(L*W*H) | 2244*1540*1852mm |
3.What is color sorter?
Color Sorters are machines that are used on the production lines in bulk food processing and other industries. They separate items by their colours, detecting the colours of things that pass before them.
The cashew sorting technology is according to the color differences of cashew materials, using a high-resolution CCD optical sensor to separate black,red,broken,small and moldy etc.Sorting machines improve product quality and add social benefits.
1. With Over 14 years experiences.focus on sorter machine.
2. After-sales service guarantee: We have a professional after-sales service team, one-on-one customer service to help customers install and w.
3. We have service station, cooperate reseller in more than 100 countries.
4. Quality assurance of raw materials: The raw materials we purchase are certified qualified products.
4. Examples of Color Sorting Examples
This product can be used in agricultural, grain, oil, chemical, pharmaceutical and other industries, especially suitable for rice, tea, sesame, beans, seeds, raisins, plastic, ore, peanut, pepper, and other color sorting field.
Compared with manual sorting, a color sorter machine is labor-saving, time-saving, high efficiency with much lower processing cost, it can dramatically improve material accuracy to bring economic and social benefits for customers all over the world.
5. FAQ
Oem is welcome ,Just need give Pantone Code of your logo to us
7-10 days for order quantity 1 set;
For more than 3 sets, usually 20 days.
Yes, for the order quantity more than 2 sets, please contact us to get the best price.
Yes, each step of production and finished products will be came out inspection by QC department before shipping.
6. Can you supply the accessories parts of color sorter?
Yes,we can supply some spare parts when you need
6. Real Photo of WYCS5-320 in customer side
7.Our After-Sale Service
We will test your products at your plant, training your staff, set every file for customer to serve all round service, so as to ensure your machine working under the best situations.
From the date of use machine, we can provide one year free maintenance ( not the reason of vandalism and something unexpected, excluding delicate fittings) and lifetime maintenance.
Engineers available to service machinery overseas, we also can train technical staff for customers.We provide lifelong software upgrade services for our customers for free.
8.Packing and Delivery:
Our products use professional wooden cases with PE plastic bag.
