320 Channel High Sorting Accuracy Intelligent Automatic Color Sorting Machine for Minerals and Aluminium Copper

320 Channel High Sorting Accuracy Intelligent Automatic Color Sorting Machine for Minerals and Aluminium Copper

High Definition Quartz Stone Color Sorter

Stone Color Sorting Machine 320 Channel

Place of Origin:

China

Brand Name:

WENYAO

Certification:

CE & ISO9001

Model Number:

WYCS5-320

Contact Us

Request A Quote
Product Details
Machine Name:
Mineral Color Sorter Machine
Model:
WYCS5-320
Function:
Color&shape Sorting
Warranty:
2 Years
HS Code:
843710
Camera Quanitity:
16pieces
Key Selling Points:
High Sorting Accuracy
Lens:
Japan Nikon Lens
Application:
Mineral,mine,quartz,aluminium&copper
After-sales Service Provided:
24*7 Online After-sale Support
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
Negotiable
Packaging Details
Plywood case package Packing size(L*W*H):3.95*1.72*2.05M
Delivery Time
3-5 work days
Payment Terms
L/C,D/A,D/P,T/T,Western Union,
Supply Ability
200PCS Per Month
Product Description
High Definition Quartz Stone Color Sorting Machine 320 Channel Intelligent Automatic Aluminium Copper Color Separator
Product Overview

High quality High Definition Quartz Stone Color Sorting Machine 320 Channel from China

CCD color sorter is a high-tech product integrating optics, machinery, and electronics, combining embedded systems with digital image processing technology. The product utilizes high-speed digitalized modules and advanced image processing to achieve high-precision sorting. Its intelligent modular structure with innovative channel encoding and decoding techniques significantly improves product stability and reliability. The AI-powered parameter setting system ensures easy operation for users.

Device Features
  • Camera: Japanese lens, Toshiba sensors with 16 megapixels (5400 CCD) micro-color detection capability
  • Germany's OSRAM LED lighting
  • American ALTRA Processor
  • Japanese SMC Pneumatic Systems
  • 12-inch NEC monitors
  • Vision's production ejectors with lifetime guarantee
  • Equipped with dust absorption system
  • AI-powered automatic device adjustment
  • Scanning capability up to 30,000 times per second, delivering three times more performance than other sorters
  • Persian Software with upgrade capability
  • Reduced energy consumption
Technical Parameters
Parameter Specification
Model WYCS5-320
Chutes/Channels 5/320
Throughput 5-10t/h
Sorting Accuracy ≥99.99%
Power 2.9kw
Power Voltage 180-240V/50Hz/60Hz
Air Source Pressure 0.6-0.8Mpa
Air Consumption 1.3-2.8M³/Min
Weight 900kg
Dimension (L*W*H) 2244*1540*1852mm
Applications
Agriculture Color Sorter

Used for: Rice, Wheat, Corn, Soybean, Peanut, Nut, Grain, Cereal, Seeds, Bean, Sunflower seeds, Walnut, Almond, Quinoa, Salt, Medlar, Pistachio, Kidney bean, Red bean, Black bean, Green bean, Coffee bean, Fava bean, Mung bean, Millet, Sorghum, Peeled garlic, Dehydrated garlic, Lotus seed, Sesame, Pine nut kernel, Watermelon seeds, Cotton seeds, Melon seeds, Buckwheat, Oats, Barley, Cardamon, Pea, Lentil, Cashew, Raisin, Jujube, Vegetables, Sugar, Onion, Potato, Blueberry, Tomato, Mango, Chickpea, Olives, Chili, and others.

Industrial Product Color Sorter

Used for: Waste Plastics, Plastic pellet, Plastic pieces, Plastic granule, Plastic bottle cap flake, PET bottle scrap, ABS plastic flake, PP plastic scrap, Recycled plastic, Quartz stone, Quartz sand, Potassium feldspar, Barite, Calcite, Limestone, Pearl, Marble and others.

River & Sea Food Color Sorter

Used for: Dried shrimp, fish, small fish clove and similar products.

Customized Solutions

Can be customized according to customer-specific color selection programs.

Color Sorter Sorting Effects
Color sorter sorting effects for minerals and aluminium copper Close-up view of color sorter sorting process
Our Service
Pre-sale Service

We provide detailed solutions for your special requirements and help you understand our color sorter technology.

After-Sale Service
  • Two-year warranty policy from shipment date
  • Replacement parts sent after receiving broken components
  • Customs risk evaluation and safest shipping company selection
  • Continuous status tracking until goods arrival
Packaging and Delivery
Professional packaging of color sorter Color sorter delivery process
Packaging Details

Our products use professional wooden cases with PE plastic bags. Package size depends on each model specification.

Delivery Details

Delivery within 3-5 days after receiving 30% deposit.

Customers' Cases
Customer installation case of color sorter Color sorter in customer facility
Frequently Asked Questions
Q: Are you a factory or trading company?
A: Wenyao designs and offers advanced products and solutions meeting global standards, features, and quality requirements. We fully comply with CE, ISO9001, ISO14001 management systems, providing great confidence and reliability. We warmly welcome clients worldwide to visit our factory and cooperate with us.
Q: How we can trust you?
A: We are a golden supplier with over 10 years of production and sales experience. We accept Alibaba Trade Assurance payment, securing your rights. In some countries, we have agents who can offer assistance.
Q: How long is your lead time?
A: Generally about one week for in-stock goods. About one month for FCL bulk orders. Exact lead time depends on actual situation - contact sales for precise information.
Q: Do you provide samples? Is it free or extra?
A: Clients need to pay for samples and freight, but payment can be refunded when placing bulk orders.
Q: What is your terms of payment?
A: Multiple payment methods available: 1. TT wire transfer, 2. Western Union or , 3. L/C, 4. Cash. Clients can choose according to their conditions.
Q: What's your transport way?
A: For large volume goods, we ship by sea to save costs. For samples or small volumes, we use express or air shipping. Contact sales for favorable suggestions.
Q: Do you offer overseas service? Installation, debugging, training?
A: Yes, we offer overseas services. Related expenses (tickets, VISA, accommodation, workers' salary etc.) shall be borne by the buyer.
Q: Do you accept products Inspection?
A: Yes, we accept product inspection. Clients can inspect themselves or entrust third parties like MIS, ITS, BV, TUV, Y'S, SQ etc. Inspection fees shall be borne by the buyer.
