Place of Origin:
CHINA
Brand Name:
WENYAO
Certification:
CE
Model Number:
WYCS4-256
Contact Us
A color sorter is an automated machine that sorts objects based on their color. It uses a combination of sensors and mechanical components to identify and separate objects of different colors. Color sorters are commonly used in industries such as textiles, plastics, and food processing to quickly and accurately sort products by color. They can also be used in manufacturing and packaging to streamline the production process and improve product quality. Color sorters are often used in conjunction with other quality control measures to ensure that only products of the desired color are packaged and shipped.
While manufacturers make different types of color sorting machines, most fall within these three primary types:
A chute sorter has rows of optical sensors all along its product chutes, which operate simultaneously to ensure comprehensive and accurate detection. These machines can sort a high volume of material quickly, making them ideal for high-capacity production lines.
This type of sorter uses a conveyor belt that moves the material past a single optical sensor. As the objects don’t move as much, they’re far less prone to breakage, so many businesses use this type of sorter for delicate items.
Optical color sorting uses lasers or cameras to sort bulk products automatically. This non-destructive machine can recognize a product’s structure, shape, defect size, and chemical composition and has a 100% inspection rate.
| MODEL | WYCS4-256 |
| Chutes(channels) | 4(256) |
| Sorting accuracy(%) | ≥99.9 |
| Carryover rate (bad:good) | ≥30:1 |
| Output(T/h) | ≥2 |
| Voltage | 180-240V/50Hz |
| Power supply(kw) | 2.3 |
| Work Air Pressure(Mpa) | 0.2-0.3 |
| Air consumption(L/min) | 1000-2400 |
| Air supply(Mpa) | 0.6--0.8 |
| Dimension(L*W*H) mm | 1854*1560*1840 |
| Weight(kgs) | 750 |
| Package | Plywood case |
| Package Size mm | 2160*1680*2060 |
Our Grain Color Sorter is perfect for sorting grain by color. With high sorting precision and accuracy, it has a low power consumption and is compact in size. The installation is simple.
Choose WENYAO for your Color Sorter For Grain needs. Our customization services ensure that our Grain Sorter By Color meets your specific requirements.
First, the CCD color sorter determines the light transmittance and color depth of the material in its feeding hopper by:
Now, consider the second working principle: when the mechanical separations begin, the materials must be distributed evenly into each channel. Then, the CCD camera in the sorting cabinet will detect the steadily flowing product. Upon identifying unqualified materials, the main control machine activates the spray valve, and the rejected product accelerates into the defective hopper.
Color sorters are integral to many businesses, particularly in the agricultural and food processing industry. For example, a color sorter can display seed images and swiftly sort through grains and harvested products with rapid efficiency, including:
Why Choose Wenyao Color Sorter?
1. Over 17 years experience which focus on sorter machine. One of the most advanced manufacturer in Hefei, Anhui.
2. After-Sales service guarantee: We have a professional after sales service team, one-to-one customer service to help customers install and debug.
3. We have service station over Southeast Asia, cooperate reseller in more than 100 countries.
4. Quality assurance of raw materials: the raw material we purchase are certified qualified products.
5. Quality process assurance: We have been authorized by CE & ISO quality management system, each process of production are under strictly standard.
6. System test: Our technical engineers check the product performance, even every part is subjected to rigorous aging test to ensure that the factory products would being in full compliance with customer requirements.
7. Shipping guarantee: We have professional packaging operation team, independent export qualification to ensure product safety and stability to reach customers in hands.
High-speed electromagnetic ejector
Imported metal magnetic levitated egector,passed 2 billion times pressure test. Durable,fast response,precise detection, improve accuracy, and reduce energy consumption.
High-speed transmission system
Ethernet access system,data standardization,gigabit ethernet,high-speed transmission system, high-tech support TP/TCP protocol, Internet remote maintenance function. It can process configuration management, performance management,fault management and security management.
Flexible mode wide application
Different materials, design the corresponding pattern. One machine can achieve different materials' screening.(Meet the color sorting requirement of hundreds of millions products such as agricultural products, industrial products and other special materials)
