Optical cardamom colour sorting machine Multifunction

Optical cardamom colour sorting machine Multifunction

Cardamom Color Sorter Machine

Multifunction Cardamom Sorting Machine

Multifunction Cardamom Colour Sorting Machine

Place of Origin:

China

Brand Name:

wenyao

Certification:

CE

Model Number:

WYCS1-64

Contact Us

Request A Quote
Product Details
Warranty:
2 Years
Voltage:
220v/50hz Or 60hz
Sorting Accuracy:
99.95%
Machinery Function:
Color And Size Sorting
Power:
0.750kw
Capacity:
500-800kg/h
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
8000-1080usd
Packaging Details
Wooden case
Delivery Time
7-15working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
600pcs per month
Product Description

Optical Cardamom Grader Machine Cardamom Color Sorting Sorter Grader Cardamom Separator Machine





Raw materials are put into the machine from its material hopper on the top, vibrated by vibratory feeder and sliding along material chute into the zone of observation in sorting chamber through sensors and background plate. Under the effect of lamps source, CCD sensor receives compound light from materials being sorted. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve(ejector) to work, ejecting the discolor grain to reject chamber and good materials continue to fall into the finished accept chamber

Color sorting machine working principle:

Optical cardamom colour sorting machine Multifunction 0

Machine Features:

CCD Camera Japanese TOSHIBA 5340 line
ar CCD, core guarantee of high precision and quick sorting , the smallest to 0.04mm could be locked.

LED system

What is a CCD in a camera?

Stands for "Charged Coupled Device." CCDs are sensors used in digital cameras and video cameras to record still and moving images. The CCD captures light and converts it to digital data that is recorded by the camera. For this reason, a CCD is often considered the digital version of film.

World leading stable long lifetime LED light, customized LED solution accepted according to specific material.

Control Unit
Advanced Image Processing System, synchronized for multiple operations and sorting mode. Adjust sorting operation to guarantee the sorting accuracy based on complex colors and shapes.

Chute System
Advanced chute design with hundreds of experiments, ensuring smooth flowing, uniform falling speed and less material consumption, optimized machine structure for disassembly and maintenance.

Ejector Valve
Italian new type of high frequency electromagnetic valve allows for accurate control of air flow power and direction with long lifetime.

Interface with Auto Testing
Self-developed auto diagnosis function with touching screen, automatically operate the testing of injector, pressure, camera, control board, background LED light and others when starting up.

Other Components
World class parts supplier, such as filter of Korea YSC and Japanese CKD. Premium quality with those famous global brands.

Optical cardamom colour sorting machine Multifunction 1

Optical cardamom colour sorting machine Multifunction 2

Optical cardamom colour sorting machine Multifunction 3

Optical cardamom colour sorting machine Multifunction 4

Optical cardamom colour sorting machine Multifunction 4

Optical cardamom colour sorting machine Multifunction 6Optical cardamom colour sorting machine Multifunction 7
