Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice

wheat color sorter machine

wheat sorting machine

Cumin Pepper Wenyao Color Sorter

Place of Origin:

Hefei China

Brand Name:

WENYAO

Certification:

CE or ISO9001

Model Number:

WYCS7-448

Contact Us

Request A Quote
Product Details
Condition:
Newest Type
MOQ:
>=1 Piece
Sorting Accuracy(%):
>=99.99%
Ejectors:
Metal Ejector
Power Supply:
Taiwan Meanwell
Touch Screen:
12-inch Flexem Humanized Display
Sensor:
Japanese TOSHIBA
Air Filter:
Korea YSC
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
Negotiable
Packaging Details
Plywood case package
Delivery Time
10-15work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
200Pieces Per Month
Product Description

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice



Color Sorters are machines used on the production lines in bulk food processing and other industries.

They sort materials by their colors or shapes, If it is found that there are unqualified materials or impurities in the materials, the ejector will blow out the rejects in the hopper.
In color sorting stage, the grain pile comes into the hopper, from there it goes into the vibrating feeder. The vibratory feeders spread and leveled the grain to a single-layer flow.Two CCD cameras are installed at the two sides of the control area. The single-stream from e.g. Cereal is scanned by the cameras. The data of the video cameras are used in the arithmetic unit and are analyzed in real time. From the results of image analysis of the signals, an air flow pulse is generated by opening the valves at the moment on the fly by the detected particle. The compressed air pulses with a pressure of (0.4--0.6 MPa), which is generated only for the duration of a few milliseconds, blowing the grain into the corresponding receiver module.

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice 0



Technical Parameters:

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice 1

MODEL WYCS7-448
Chutes/Channels 7 / 448
Throughput(t/h) 3-10t/h
Sorting Aaccuracy ≥99.999%
Power 3.9kw
Power Voltage 180-240V/50-60Hz
Air Source Pressure 0.6-0.8Mpa
Air Consumption <2.8M3/Min
Weight 1350kg
Diamension(L*W*H) 2905*1540*1852mm



Machine Features:

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice 2



Increased Productivity



1.Dedicated digital sorting engine to deliver high speed

2.Wide flat chute to increase throughput

1.

Maximized Sorting Yield

1. Sorting high speed and precise ejection to minimize good product in reject
2. Resort capability reclaims good product from reject



1.

High Sorting Accuracy

1. High speed, high resolution, full color RGB CCD camera (5400 pixels) to detect tiny defects
2. Advanced imaging technology to sort defects with minimum contrast
3. Enclosed feeding system to provide better feeding and chute protection
4. Infrared sorting (optional) to effectively sort foreign materials



1.

User Friendly Operation

1.   1. High resolution touch screen with user-friendly graphics
2.   2. Real time monitor of machine status
3    3. Easy software upgrade with USB

as



Examples of Color Sorting



Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice 3



Our Service:


Before Sale
We will provide detailed solutions for your special requirement and help you know more about our color sorter.

After Sale Service
We will test your products at your plant, training your staff, set every file for customer to serve all round service, so as to ensure your machine working under the best situations.

From the date of use machine, we can provide one year free maintenance ( not the reason of vandalism and something unexpected, excluding delicate fittings) and lifetime maintenance.

Engineers available to service machinery overseas, we also can train technical staff for customers.We provide lifelong software upgrade services for our customers for free.


Packing and Delivery

Packaging Details:
Our products use professional wooden cases with PE plastic bag.

Package size will depend on each model size.

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice 4

Delivery Detail:
Within 15 - 20 days after received deposit.

Customer Sites :

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice 5

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice 6

Hot Sale WENYAO Color Sorter Cumin Pepper Color Sorter Machine Sorting For Spice 7
