Place of Origin:
Anhui China
Brand Name:
WENYAO
Certification:
CE & ISO9001
Model Number:
WYB4
Contact Us
Video
Video
2022 Wholesale Good Quality Glass Metal Plastic Ore Powder Sorting Machine Belt Type
What is a CCD in a camera?
Stands for "Charged Coupled Device." CCDs are sensors used in digital cameras and video cameras to record still and moving images. The CCD captures light and converts it to digital data that is recorded by the camera. For this reason, a CCD is often considered the digital version of film.
Raw materials are put into the machine from its material hopper on the top, vibrated by vibratiory feeder and sliding along material chute into the zone of observation in sorting chamber through sensors and background plate. Under the effect of lamps source, CCD sensor receives compound light from materials being sorted. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve(ejector) to work, ejecting the discolor grain to reject chamber and good materials continue to fall into the finished accept chamber.
WYB4 Glass sorting machine technical parameters:
| MODEL | WYB4 |
| Chutes/Channels | 4/256 |
| Throughput(t/h) | 6-8t/h |
| Sorting Aaccuracy | ≥99.99% |
| Power | 4.5kw |
| Power Voltage | 180-240V/50Hz/60Hz |
| Air Source Pressure | 0.6-0.8Mpa |
| Air Consumption | 1-2.4M3/Min |
| Weight | 1400kg |
| Diamension(L*W*H) | 3173*1914*1420mm |
Wenyao Color Sorting Machine Highlight Features:
►5400Pixels CCD image acquisition system with high speed chip.
►Automatic computing and intelligent identification with high speed camera.
►Intelligent dust cleaning system,It means you can set cleaning time and period according to your need.
►Self design high frequency ejectors,It means high speed and accurate sorting performance.
►Low temperature LED light source system,Cooling system to make the LED lamp more long life.
►WIFI remote control system,It means color sorter connecting to the internet,You can use mobile phone or computer to operate color sorter.
►Easy to operate touch screen with english,spanish,german,russian and so on more than 20 languages.
Packing and delivery:
Packaging Details:Our products use professional wooden cases with PE plastic bag.Package size will depend on each model size.
Delivery Details:Within 15 - 20 days after received deposit.
Sorting effect :
Our custom's site:
Our service:
Pre-Sales Service:
* Inquiry and consulting support.
* Sample testing for free support.
* View our Factory.
After-Sales Service:
* Video indication about machine installment and operation;
* Training how to install the machine, training how to use the machine for free.
* Engineers available to service machinery overseas.
* 7*24 online service hot-line.
* Life-long service for net cost spare parts
