Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera

Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera

2 Chutes Herbal Color Sorter

Digital Herbal Color Sorter Machine

CCD Camera Herbal Color Sorter

Place of Origin:

China Hefei

Brand Name:

WENYAO

Certification:

CE AND ISO9001

Model Number:

WYCS2-128

Contact Us

Request A Quote
Product Details
Sorting Accuracy(%):
≥99.99%
Condition:
Newest 2022 Color Sorting Machine For Herbal
Color:
Customized And Random Color
Warranty:
2 Years
After-sales Service Provided:
Field Maintenance And Repair Service Avaliable
Application:
Plastic Recycling Line
MOQ:
>=1 Set
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
Negotiable
Packaging Details
Plywood case package Packing size(L*W*H):3.20*1.72*2.05M
Delivery Time
7-15 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
250PCS Per Month
Product Description

Digital 2 Chutes 4 Vibrators Special Herbal Color Sorter Machine For Herbal Color Sorting With CCD Camera



WENYAO Color Sorter Machine Working Flow:

Raw materials are put into the machine from its material hopper on the top, vibrated by vibratiory feeder and sliding along material chute into the zone of observation in sorting chamber through sensors and background plate. Under the effect of lamps source, CCD sensor receives compound light from materials being sorted. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve(ejector) to work, ejecting the discolor grain to reject chamber and good materials continue to fall into the finished accept chamber.



Color Sorters are machines used on the production lines in bulk food processing and other industries.They sort materials by their colors or shapes, If it is found that there are unqualified materials or impurities in the materials, the ejector will blow out the rejects in the hopper.


Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera 0





Technical Parameters:

Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera 1

MODEL WYCS2-128
Chutes/Channels 2/128
Throughput(kg/h) 500kg-750kg/h
Sorting Aaccuracy ≥99.99%
Power 1.1kw
Power Voltage 180-240V/50Hz
Air Source Pressure 0.6-0.8Mpa
Air Consumption <3.8M3/Min
Weight 450kg
Diamension(L*W*H) 1250*1535*1832mm



Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera 2





2 Chutes Plastic Color Sorter Machine Features:



►Automatic computing and intelligent identification with high speed camera.
►5400Pixel CCD image acquisition system with high speed chip.
►Intelligent dust cleaning system,It means you can set cleaning time and period according to your need.
►Self design high frequency ejectors,It means high speed and accurate sorting performance.
►Low temperature LED light source system,Cooling system to make the LED lamp more long life.
►WIFI remote control system,It means color sorter connecting to the internet,You can use mobile phone or computer to operate color sorter.
►Easy to operate touch screen with english,spanish,german,russian and so on more than 20 languages.







Examples of color sorting:



Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera 3



Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera 4

Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera 5



After Sales Service
1.We provide customer with one year free repair and maintenance for complete machine.
2.We also provide lifetime professional training and technical guidance service.


FAQ
1.Q:How about engineers service oversea?
A:Engineers available to service machinery overseas.
2.Q:How to use the machine?
A:We will supply customer the installation catalog or video online.We will ask our engineer to teach you, how to use when he go to your country to debug the machine.
3.Q:How about the sample machines for testing?
A:Sample sending for testing is welcomed.Or you send these three photos,the raw material,good material (which is you want) ,bad material (which is you want to discard).We send our video to you.
4.Q:How about the guarantee period?
A:One year.
5.Q:Will you accept L/C as payment?
A:L/C ,T/T is OK.
6.Q:Do you have any other spare parts for the customer?
A:Yes,we will supply you some spare parts.
7.Q:Which machine will work together with our color sorter which you can supply?
A:Air compressor,Air tank,Air filters,Air dryer,Light sources,Cleaning brushes,etc


Packing Details
Digital 2 Chutes 4 Vibrators Herbal Color Sorter Machine With CCD Camera 6
