High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting

High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting

High Intelligent Hazelnut Color Sorter

Deep Learning Hazelnut Color Sorter

Nuts Sorting Hazelnut Color Sorter

Place of Origin:

China

Brand Name:

WENYAO

Certification:

CE & ISO9001

Model Number:

WYCS10-640

Contact Us

Request A Quote
Product Details
Features:
Easy To Operate
Structure:
Freefall
Type:
CCD
Transport Package:
Wooden Box
HS Code:
8437101000
Origin:
Hefei
Brand Of Power Supply:
Taiwan Meanwell
Process Chip:
America Fpga
Type Of Ejectors:
Metal
Pixels Of Camera:
5400
Light Source:
LED
Name:
Optical Sorting Machine
CCD Sensor:
Full Color RGB
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
Negotiable
Packaging Details
Plywood case package Packing size
Delivery Time
15-20 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
200PCS Per Month
Product Description

Wenyao High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting



color sorter is a high-tech product that integrates optics, machinery, electronics, and pneumatics, and has the function of secondary sorting. The basic working principle of the color sorter is to feed the material through the feeder, allowing the material to pass uniformly through the viewing point. The CCD camera captures the color and shape information of the material and sends the data to the data processing unit for image processing and threshold selection. Finally, the defective materials are rejected by high-frequency electromagnetic valves.

This product uses high-speed and high-sensitivity linear CCD as the sensor for material color and shape. It adopts a SOC-based platform architecture, which, compared to the DSP platform, increases the CPU frequency by 5 times and improves the output processing capacity by 4 times. This achieves stable and reliable, ultra-high-speed massive data processing. As a result, this product outperforms similar color sorters in terms of minimum resolution, color sorting accuracy, color sorting efficiency, and other performance aspects.



Established in 2007: Have rich experience and strong strength.

Artistic appearance: Original piano frame and artistic design; Arc transition design - beautiful, simple and three-dimensional.

Observation recognition: Original multi-spectral confocal technology; Holographic flash camera; Infrared intelligent sorting technology; Low temperature concentrated LED light source; Shape sorting technology; RGB spectrum technology.

Intelligent interconnection: The simplest UI; One button to an intelligent mode; One button to an intelligent mode; Original 4G high-speed online service; Color sorting assistant; Intelligent sorting technology; Intelligent deashing 2.0.

Outstanding output: Deashing of air flow; Deashing of air flow; Self-adaptive feeding.

Intelligent elimination: Self-collaborative sensing technology; Central position elimination technology; High end customized valves.

Intelligent Holographic Flash Camera Compatible with CMOS or CCD image sensors

Flexible switch between visible lens or infrared lens35K high-speed imaging +350 million pixel ultra-clear resolution



LED light source

Flexible Light Source Configuration: For different raw

material, the Color LED illumination system can choose use different spectrum for the illumination to increase the contrast and increase the precision of information

acquisition. The LED illumination system has the cooling system, so the system has the long lifetime, low energy consumption and high performance.

Dedicated Image Processing Algorithm According to the characteristics of material, use the shape and color combination algorithm; For materials with

complex colors, the machine sorts materials more directly and accurately by using HSV-changed color space sorting method.

High-Quality Solenoid Valve

Use High-quality,high-frequency,long service life ejecter, super low air consumption guaranteed the biggest capacity, excellent rejection output. For the different sizes and

characteristics of material particle, use the solenoid valve of different sizes.



Simple Operation

Simple optical system design, precise automatic correction system, combined with the well-designed human-

machine interface to simplify the complexity of machine commissioning and use, ensuring the simple operation and the machine is easy to learn and use.





Details as following
MODEL WYCS10-640
Chutes(channels) 10(640)
Sorting accuracy(%) ≥99.9
Carryover rate (bad:good) ≥30:1
Output(T/h) 10
Voltage 180-240V/50Hz
Power supply(kw) 6.5
Work Air Pressure(Mpa) 0.2-0.3
Air consumption(L/min) 2600-5000
Air supply(Mpa) 0.6--0.8
Dimension(L*W*H) mm 3630*1545*1860
Weight(kgs) 1800
Package Plywood case
Package Size mm 3764*1554*1871



Technical Parameters:





Color sorter work principle:



High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 0


Digital Intelligent Garlic Color Sorter Machine

*Optical Sorting Technology With High Resolution 4096 Pixel CCD Camera,High Reliability And Long Life LED Light Source;

*Efficient And Stable Software System,Intelligent Algorithm,User Friendly Interface;

*Installing in Flour milling processing plant with Better Sorting Accuracy, Lower Carryover, And Bigger Production Capacity;

*Wheat Sorting Machine With SOC Platform To Realize Stable, Reliable, Ultra-Fast Mass Data Processing;

*Expert Sorting Solution Realizes One Key Debugging

Examples of color sorting:



High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 1High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 2High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 3High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 4High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 5High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 6





Why Choose Wenyao Color Sorter?

1. Over 17 years experience which focus on sorter machine. One of the most advanced manufacturer in Hefei, Anhui.

2. After-Sales service guarantee: We have a professional after sales service team, one-to-one customer service to help customers install and debug.

3. We have service station over Southeast Asia, cooperate reseller in more than 100 countries.

4. Quality assurance of raw materials: the raw material we purchase are certified qualified products.

5. Quality process assurance: We have been authorized by CE & ISO quality management system, each process of production are under strictly standard.

6. System test: Our technical engineers check the product performance, even every part is subjected to rigorous aging test to ensure that the factory products would being in full compliance with customer requirements.

7. Shipping guarantee: We have professional packaging operation team, independent export qualification to ensure product safety and stability to reach customers in hands.



Customer's Site :



High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 7

High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 8

High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 9

High Intelligent Deep Learning Hazelnut Color Sorter Machine Nuts Sorting 10




Why choosing Wenyao color sorter

1,Advanced image acquisition system
color sorter machine use the high resolution monochromatic camera or RGB camera(5000+ pixels) with high quality industrial lens to achieve clear and accurate image acquisition.The camera could capture the micro defects of material instantly.

2,Intelligent image processing algorithm
Color sorting algorithms of gray level,color difference and HSV are perfectly combined with shape sorting algorithms of size,circular degree,texture etc,and successfully solved a series of high difficulty color sorting problems,and dramatically enhance the sorting accuracy.

3,Unique chutes processing technology
The special anodizing and hardening technology can greatly improve the channel smoothness and ware resistance to guarantee high production.

4,High quality solenoid valve(ejector)
color sorters are equipped with high quality solenoid valve.The valve has longer lifespan,high frequency and low air consumption.The working frequency is 1000 times per second,which guarantees the accurate and perfect ejecting.For the different sizes and characteristics of material particle, NAGE optical sorters use the solenoid valve of different sizes.

5,High efficiency and reliable light source
Advanced LED lighting technology with advantages of super high intensity,long lifetime&perfect performance.

6,Simple operation, easy to learn and use
Simple optical system design, precise automatic correction system, combined with the well-designed human-machine interface to simplify the complexity of machine commissioning and use, ensuring the simple operation and the machine is easy to learn and use.



Rice: white/black/red/yellow/barley rice

Wheat: buckwheat/quinoa/oatmeal

Corn: corn particles/white corn/ ellowcorn/black corn

Beans: soybeans/mungbeans/red beans/broad beans

Nuts: peanuts/cashew nuts/walnut meat/pine nuts Dry food: dry onion/ raisins/dried chilli

Seeds: sunflower seeds/ rice seeds/ vegetable seeds

Industrial materials: plastic/scrap metal/ broken galss/ coal/ore/slag
