Place of Origin:
CHINA
Brand Name:
WENYAO
Certification:
CE
Model Number:
WYCS4-256
Contact Us
Intelligent interconnection: The simplest UI; One button to an intelligent mode; One button to an intelligent mode; Original 4G high-speed online service; Color sorting assistant; Intelligent sorting technology; Intelligent deashing 2.0.
Outstanding output: Deashing of air flow; Deashing of air flow; Self-adaptive feeding.
Intelligent elimination: Self-collaborative sensing technology; Central position elimination technology; High end customized valves.
17 Years Of Deep Cultivation In Color Sorting, Doubled Production: 17 years of deep cultivation in color sorting, both internal and external improvements, and doubled production. With new evolution, improved efficiency and increased production, platform-based models, upgraded modular structure, load increased by 3-5 times, feeding and rejection system efficiency increased by 30%, dust removal optimized by 50%, and production increased by 66%.
Hundreds Of Algorithms To Identify Colors And Shapes: Hundreds of algorithms have been developed to identify colors and shapes. Shape and color selection by AI empowerment, intelligent system, identification as fine as 0.15mm, 350 million pixels ultra-clear resolution, new shape selection algorithm for yellow, white, transparent, long, round, and broken materials.
Thousand Process Quality Inspections, Consistent Quality: Nearly a thousand process quality inspections, consistent quality, and excellence. Thousands of quality inspections, quality control, standardized production, more stable equipment effects, SOC smart core matching intelligent high-frequency solenoid valve, blowing thousands of times per second, lower carry-out, higher clean rate.
Cooperating With 10000+ Customers, Worry-Free After-Sales: Cooperating with tens of thousands of customers, intelligent interconnection, worry-free after-sales. We are listed brand with strong strength, we offer customized service 24/7 online, and real-time response in the cloud. Including user profile creation for tracking service, equipment can be intelligently interconnected to achieve remote operation and maintenance.
| MODEL | WYCS4-256 |
| Chutes(channels) | 4(256) |
| Sorting accuracy(%) | ≥99.9 |
| Carryover rate (bad:good) | ≥30:1 |
| Output(T/h) | ≥2 |
| Voltage | 180-240V/50Hz |
| Power supply(kw) | 2.3 |
| Work Air Pressure(Mpa) | 0.2-0.3 |
| Air consumption(L/min) | 1000-2400 |
| Air supply(Mpa) | 0.6--0.8 |
| Dimension(L*W*H) mm | 1854*1560*1840 |
| Weight(kgs) | 750 |
| Package | Plywood case |
| Package Size mm | 2160*1680*2060 |
INTELLIGENT OPERATION SYSTEM
Overall Large Screen HD Operation control panel, 1080P Super high resolution,system more stable, more friendly Human-Machine-Interface panel, which gives high sensitivity instant fast repones in the industrial environment.
NEWLY SPECIAL SUPER WIDTH CHUTE DESIGN
Special technology chutes, applicable for universal materials,make the transfer more steady, more capacity.
MECHNICAL RECONSTRUCTION
Reconstrution of the mechnical frame, the main part with special material,balancing whole frame bearing, ensure the machine integrity. Working with the updated mechanism, it strength the base of the ultra-sorting.
SELF-DEVELOPED SPRAY VALVE
Self-developed spray valve, Self-developed high-performance spray valve, super high rapid response to the Algorithm results. It can continuously working 12billion+ times, extremely long life, with low air consumption,master the core technology.
ILLIMITABLE SORTING POSSIBILITIES, START BY “ONE BUTTON” PRESSURING
Hundred of sorting profiles can be saved in machine machine, for the variety products for sorting, subdivide the quality of agric and sideline products illimitable sorting possibilities,“one button”start, “one button”profiles exchange.
SHADOWLESS COLD LIGHT SOURCE,AUTOMATICA ADJUSTABLE
Extremely long life, low energy consumption intellligent shadowless cold light source, orthogonal spectrum technology, make the image more visiable, more accuracy detection; the output luminance of light source are automatically adjustable, it make the lights more stable with high quality. It is fully appliable for the camera to see and detect.
Why Choose Wenyao Color Sorter?
1. Over 17 years experience which focus on sorter machine. One of the most advanced manufacturer in Hefei, Anhui.
2. After-Sales service guarantee: We have a professional after sales service team, one-to-one customer service to help customers install and debug.
3. We have service station over Southeast Asia, cooperate reseller in more than 100 countries.
4. Quality assurance of raw materials: the raw material we purchase are certified qualified products.
5. Quality process assurance: We have been authorized by CE & ISO quality management system, each process of production are under strictly standard.
6. System test: Our technical engineers check the product performance, even every part is subjected to rigorous aging test to ensure that the factory products would being in full compliance with customer requirements.
7. Shipping guarantee: We have professional packaging operation team, independent export qualification to ensure product safety and stability to reach customers in hands.
Our Grain Color Sorter product comes with comprehensive technical support and services to ensure smooth operation and maximum performance. Our team of experienced technicians and engineers are available to provide remote and onsite support, as well as training and consultation to help customers optimize their sorting process.
Our technical support services include troubleshooting and diagnosis of any technical issues, as well as recommendations for repair and replacement of parts. We also offer regular maintenance and calibration services to ensure that the machine continues to operate at peak efficiency.
In addition to technical support, we also offer customization services to meet unique sorting needs of our customers. This includes developing custom software and hardware modifications to enhance sorting accuracy and speed.
Our commitment to customer satisfaction means that we are always available to answer any questions or concerns related to our product. We strive to provide the highest level of support and service to help our customers achieve their sorting goals.
Q: What is the brand name of this grain color sorter?
A: The brand name of this grain color sorter is WENYAO.
Q: What is the model number of this grain color sorter?
A: The model number of this grain color sorter is WYCS4-256.
Q: Where is this grain color sorter manufactured?
A: This grain color sorter is manufactured in China.
Q: Is this grain color sorter certified?
A: Yes, this grain color sorter is certified with CE.
Q: What is the minimum order quantity for this grain color sorter?
A: The minimum order quantity for this grain color sorter is 1.
Q: What are the payment terms for this grain color sorter?
A: The payment terms for this grain color sorter are T/T and L/C.
Q: What is the supply ability for this grain color sorter?
A: The supply ability for this grain color sorter is 50 sets per month.
