Place of Origin:
CHINA
Brand Name:
WENYAO
Certification:
CE
Model Number:
WYCS4-256
Contact Us
The powerful AI algorithm ensures the processing speed and accuracy of the wenyao color sorter, which is dependent on the ultra-high-speed camera to capture images and achieve a lower takeout ratio. Real-time monitoring and feedback capabilities help customers quickly identify and resolve any potential issues. This helps improve efficiency and reduce downtime in production.
Advanced Image Acquisition
With 162 million pixel, super high-resolution full color Toshiba CCD camera, subtlest defect as 0.01mm*mm can be sorted out(Bad spot value can be adjusted according to different materials and customers' requirement, to meet different batch and impurities rate sorting requirement)
Remote Control and One-Key Operation
Brand new anti-rust UV chute
Wide-angle design, anti-rust and non-toxic&harmless aluminium alloy, in line with international safety standards, ensure he smooth slide of the material, and reduce waste, and achieve the maximization of capacity. Customizable according to different materials.
Intelligent Imagine Processing System
High identification, scan speed up to 30,000 times per second real time big data analysis can fullfil all complex algorithms.
Germany High Luminance LED Light
Shadowless LED lighting system, with high luminance, long life source, precise detectioin,stable
frequency,which ensure high sorting accuracy
High-speed electromagnetic ejector
Imported metal magnetic levitated egector,passed 2 billion times pressure test. Durable,fast response,precise detection, improve accuracy, and reduce energy consumption.
High-speed transmission system
Ethernet access system,data standardization,gigabit ethernet,high-speed transmission system, high-tech support TP/TCP protocol, Internet remote maintenance function. It can process configuration management, performance management,fault management and security management.
Flexible mode wide application
Different materials, design the corresponding pattern. One machine can achieve different materials' screening.(Meet the color sorting requirement of hundreds of millions products such as agricultural products, industrial products and other special materials)
| MODEL | WYCS4-256 |
| Chutes(channels) | 4(256) |
| Sorting accuracy(%) | ≥99.9 |
| Carryover rate (bad:good) | ≥30:1 |
| Output(T/h) | ≥2 |
| Voltage | 180-240V/50Hz |
| Power supply(kw) | 2.3 |
| Work Air Pressure(Mpa) | 0.2-0.3 |
| Air consumption(L/min) | 1000-2400 |
| Air supply(Mpa) | 0.6--0.8 |
| Dimension(L*W*H) mm | 1854*1560*1840 |
| Weight(kgs) | 750 |
| Package | Plywood case |
| Package Size mm | 2160*1680*2060 |
INTELLIGENT OPERATION SYSTEM
Overall Large Screen HD Operation control panel, 1080P Super high resolution,system more stable, more friendly Human-Machine-Interface panel, which gives high sensitivity instant fast repones in the industrial environment.
NEWLY SPECIAL SUPER WIDTH CHUTE DESIGN
Special technology chutes, applicable for universal materials,make the transfer more steady, more capacity.
MECHNICAL RECONSTRUCTION
Reconstrution of the mechnical frame, the main part with special material,balancing whole frame bearing, ensure the machine integrity. Working with the updated mechanism, it strength the base of the ultra-sorting.
SELF-DEVELOPED SPRAY VALVE
Self-developed spray valve, Self-developed high-performance spray valve, super high rapid response to the Algorithm results. It can continuously working 12billion+ times, extremely long life, with low air consumption,master the core technology.
ILLIMITABLE SORTING POSSIBILITIES, START BY “ONE BUTTON” PRESSURING
Hundred of sorting profiles can be saved in machine machine, for the variety products for sorting, subdivide the quality of agric and sideline products illimitable sorting possibilities,“one button”start, “one button”profiles exchange.
SHADOWLESS COLD LIGHT SOURCE,AUTOMATICA ADJUSTABLE
Extremely long life, low energy consumption intellligent shadowless cold light source, orthogonal spectrum technology, make the image more visiable, more accuracy detection; the output luminance of light source are automatically adjustable, it make the lights more stable with high quality. It is fully appliable for the camera to see and detect.
Why Choose Wenyao Color Sorter?
1. Over 17 years experience which focus on sorter machine. One of the most advanced manufacturer in Hefei, Anhui.
2. After-Sales service guarantee: We have a professional after sales service team, one-to-one customer service to help customers install and debug.
3. We have service station over Southeast Asia, cooperate reseller in more than 100 countries.
4. Quality assurance of raw materials: the raw material we purchase are certified qualified products.
5. Quality process assurance: We have been authorized by CE & ISO quality management system, each process of production are under strictly standard.
6. System test: Our technical engineers check the product performance, even every part is subjected to rigorous aging test to ensure that the factory products would being in full compliance with customer requirements.
7. Shipping guarantee: We have professional packaging operation team, independent export qualification to ensure product safety and stability to reach customers in hands.
Our Grain Color Sorter product comes with comprehensive technical support and services to ensure smooth operation and maximum performance. Our team of experienced technicians and engineers are available to provide remote and onsite support, as well as training and consultation to help customers optimize their sorting process.
Our technical support services include troubleshooting and diagnosis of any technical issues, as well as recommendations for repair and replacement of parts. We also offer regular maintenance and calibration services to ensure that the machine continues to operate at peak efficiency.
In addition to technical support, we also offer customization services to meet unique sorting needs of our customers. This includes developing custom software and hardware modifications to enhance sorting accuracy and speed.
Our commitment to customer satisfaction means that we are always available to answer any questions or concerns related to our product. We strive to provide the highest level of support and service to help our customers achieve their sorting goals.
Q: What is the brand name of this grain color sorter?
A: The brand name of this grain color sorter is WENYAO.
Q: What is the model number of this grain color sorter?
A: The model number of this grain color sorter is WYCS4-256.
Q: Where is this grain color sorter manufactured?
A: This grain color sorter is manufactured in China.
Q: Is this grain color sorter certified?
A: Yes, this grain color sorter is certified with CE.
Q: What is the minimum order quantity for this grain color sorter?
A: The minimum order quantity for this grain color sorter is 1.
Q: What are the payment terms for this grain color sorter?
A: The payment terms for this grain color sorter are T/T and L/C.
Q: What is the supply ability for this grain color sorter?
A: The supply ability for this grain color sorter is 50 sets per month.
