*5340 linear CCD camera with high precision allows high definition identification and high speed sorting.
*Most advanced ccd technology can sort materials accurately.
*Toshiba CCD sensor
*American process chip
Place of Origin:
China
Brand Name:
WENYAO
Certification:
CE
Model Number:
WYB2
Contact Us
Video
For the removal of contaminants from glass cullet (ceramics, stones, porcelain, metals) and for the separation of glass by wenyao color sorting system, the all-in-one optical sorter for glass recycling applications. It’s solid-state design (no moving parts!) and can be used for average particle sizes between about ¼” and two inches (6-50mm).
To eliminate contaminants from glass cullet (ceramics, stones, porcelain, metals) and to separate glass by the Wenyao color sorting system, the all-in-one optical sorter for glass recycling applications is employed. It is applicable for average particle sizes ranging from 6 to 50mm.
A completely novel development utilized in the recycling of thin-sheet, container, and flat glass, the Wenyao color sorter can segregate unwanted color particles, ceramics, stones, and porcelain from the cullet flow with a minimum loss of good material. It can also detect and eliminate special glasses. The space-efficient design is conducive to minimizing glass breakage and incorporates new specific light technology. These attributes enable a higher throughput capacity with precise detection. The AI system distinguishes contaminants and glass by color and will remove "out of specification" glass from the material flow that is indiscernible to the human eye. Unwanted materials are expelled from the material flow by air-ejection nozzles operating within one millisecond. For further information, please contact us without hesitation.
| MODEL(Technical Parameters) | WYB2 |
| Channels | 128 |
| Output(kg/h) Depend on raw material impurity | 800-2000 |
| Sorting Accuracy(%) | ≥99.9 |
| Carryover Rate(bad:good) | ≥13:1 |
| Power Supply(KW) | 2.5 |
| Work Air Pressure(Mpa) | 0.2-0.3 |
| Air Consumption(L/min) | 600-1200 |
| Voltage | 180-240V/50Hz |
| Weight(kg) | 800 |
| Diamension/Size (L*W*H)mm | 2455*1310*1540 |
| Package | Wooden Case |
ANHUI WENYAO Optoelectronic Technology Co., Ltd founded in 2007, which combined with design, manufacture and selling. We manufacture high-tech optical color sorter machine of sorting wheat, rice, tea, melon seeds, grains, coarse cereals, nuts, dried vegetables, dried seafood, plastics, ores, ect. Supply the service to customers from Asia, the Middle East European, South Africa and African markets.
Through countless cooperation and OEM service with international partners, ANHUI WENYAO has streamlined the proper procedures and processes and opened up professional techniques that are ahead of the color sorting field and delivered the highest-quality products to every corner of the world.
Through countless hardwork, we serve customers from all over the world. We have high reputation in domestic, Africa, Middle-East, South-East Asia market. Expect you to join our big family. We will never let you down.
1. How to use the machine?
We will supply the Installation instructions or video and our engineers will train your operators.
2. How long about the guarantee period?
One year. And we supply lifelong software upgrade services for our customers.
3. Can you supply the air compressor, air tank and air filters?
Yes, we can provide above equipments, our standard offer includes color sorter machine with air compressor, air tank and filters.
4. Is oversea service available?
Yes, our engineers could go abroad when required.
5.How to calculate Installation personnel cost?
On condition that customer requires to install, our company would like to send 1 Engineer to guide for installation, then customer should to pay the cost, including transaction of Engineer's visa, transportation(air) for go abroad. and accommodation , local transportation and security when the Engineer arrived.
